The interactive whiteboard is a display screen that combines the functionality of projectors, interactive whiteboards, speakers, televisions, and brief video conferencing terminals. It is evident that the video file format supports video, on-site speakers, display writing, document marking, storage, dissemination, and other official meeting requirements.
Structure of Product
Interactive whiteboard is mainly divided into four modules: LCD panel, tempered glass, dual system and shell. The different configuration of each module determines the final quality of the interactive whiteboard.
Features:
- Support Android and windows system, can double system perfect seamless switching, application more flexible, more convenient to use.
-
- Support meeting content sweep a key to take away, but also support email sharing send.
-
- With advanced screen casting technology, you can quickly cast cell phones, IPAD, laptop images to the conference screen, that is, synchronous mirror casting out to support background push.
Design of Product
4K super clear anti-glare screen display, data, video and other content can be clearly restored, the demonstration report is fantastic; The screen hardness is scratch-proof, and the writing touch is arbitrary.
Specification
| Panel Size | 75 inch |
| Resolution | 4k 3840×2160 |
| Panel back light | TFT-LCD Module |
| Panel Protection | Tempered Glass, Anti-Glare glass |
| Picture scale | 16:09 |
| refresh frequency | 60Hz |
| Panel Specification | 1.07B(10bit) |
| Gamut NTSC(Typ) | 72% |
| contrast ratio(Typ) | 5000:01:00 |
| Backlight Type | DLED |
| Life Span | ≥30000 hours |
| | Android Configuration |
| CPU | ARM Cortex A73*2 and A53*2 |
| GPU | Dual core Mali-G51 |
| RAM | 4GB |
| ROM | 32GB |
| WIFI | 2.4GHz/5 GHz |
| Bluetooth | Support |
| Android OS | Android 8.0 |
| Input/output | HDMI 2.0,VGA,TV-RF,USB 2.0,USB3.0,TF card,AV,RGB,RS232,Touch Port,Earphone,SPDIF |
| | Windows Configuration |
| CPU | i3/i5/i7 |
| RAM | 4/8/16/32 GB DDR4 |
| Internal memory | 128/256/512 GB SSD |
| Windows OS | Windows 7, 8.1, 10 |
| HDMI | HDMI 2.0 |
| USB | USB 2.0*4, USB 3.0*2 |
| RJ45 Port | RJ45*1 |
| WIFI | 2.4GHz/5 GHz |
| | Touch Screen |
| Touch Type | Infra-red |
| Points | 20 points |
| Response Time | Less than 5ms |
| Touch Way | Pen, Finger or other |
| Position Accuracy | ±1mm |
| Resolution | 32767 * 32767 |
Product customization
Support customize LOGO, System, Whiteboard software, Shell color, more customization require, plz contact our professional sales team.
Accessories of Product
We offers smart boards that are installed on the wall. The package includes a power cable, user handbook, remote control, and magnetic stick infrared stylus.
The Interactive smart board of Technology in the Classroom
Smartboard technology provides excellent opportunities to facilitate discussions between teachers and students.
For example, students can collaborate with colleagues through communication applications or share documents on virtual learning tools to work on different projects. With smartboard technology, collaboration doesn't end once students leave the classroom.
|
|
Multi Touch Smart Board Interact Screen Interactive Board Images
|
